Autoedu MSAS02 | Educational lighting training board
The MSAS02 is an advanced educational simulator housed in a mobile aluminum frame, featuring authentic VW/AUDI OEM components. It integrates a comprehensive electric wiring diagram with banana plug jumpers for precise measurements and connections. Equipped with an OBD 16-pin diagnostic connector, it supports fault code management, live data display, and ECU identification. The system allows for adjustable headlight beam levels and includes diagnostic tools such as oscilloscopes and multimeters.
- Based on VW/AUDI OEM components, utilizes authentic parts for accurate representation of automotive lighting systems.
- Integrated OBD 16-pin connector for diagnostic functions, including fault code management and live data display.
- Front headlights equipped with motors for precise beam adjustment.
- Electrical wiring diagram includes built-in banana plug jumpers and open contacts for component measurement and circuit testing.
- Compatible with oscilloscopes, multimeters, and optional headlight testers for comprehensive analysis.
- Ability to simulate faults by disconnecting jumpers and observing system changes.
- Mobile aluminum frame ensures durability and ease of movement within educational settings.
- Dimensions: 1820 x 1360 x 500 mm (71.65 in×53.54 in×19.69 in)
- Weight: approx. 60 kg (132 lb)
- Power supply: 12V battery (optional), or 220 (110V)/12V power supply unit
