Endevco 2223D | Triaxial Piezoelectric accelerometer for vibration measurement on small structure

The Endevco2223D is a triaxial accelerometer ideal for measuring vibrations in small structures. The three kinds of single axis sensors this accelerometer uses are isolated from each other and from the mounting surface by a hard-anodized isolator. This accelerometer is used for general purpose measurements and package testing. For an error-free operation, low-noise coaxial cables are supplied with this unit.

Key Features:

• ● Temperature range: -55˚C to +177˚C
• ● Typical Charge sensitivity of 12 pC/g
• ● Resonance frequency at 14 kHz in x and y axis and 28 kHz in z axis
• ● Measurement range: up to 1000 g
