MSD01 | Training board simulator for Sensors and Actuators
Designed of OEM components from different vehicles, this fully functional training board from AutoEdu is ideal to demonstrate the operation of electronics control system in automobiles. Students can perform various test and measurement activity as well as learn the correct troubleshooting and diagnostics procedure.
- Includes OEM sensors: ACT, CTS1, CTS2, MAF, TPS, Knock, and MAP sensors.
- Features voltmeter and temperature displays for real-time monitoring of sensor outputs and performance.
- PWM control allows for control and analysis of actuators such as the IAC valve, DC motor, and solenoid valve via PWM signals.
- Equipped with LED indicators for relay status, heater operation, and sensor feedback to facilitate troubleshooting and understanding of system functions.
- Safe, durable and mobile construction with internal wiring for best learning experience and safe environment.
